Rheem Gas Water Heater
Fury models

Fury Heavy Duty, Direct Vent and Ultra Low NOx models

Rheem gas water heater from Fury gas series, can be found in variety of capacity ranges and efficiency, designed for both residential water heating and commercial applications.


Review of Fury series

Rheem Fury gas series consists of several groups utilizing the most advanced Rheem's features. Some water heaters are tall or short in size, green, and high efficient or Energy Star compliant:

  • Fury series with the Guardian System

  • Fury Ultra Low NOx Powered Damper Series

  • Fury Powered Damper Series

  • Fury Heavy Duty Series

  • Fury Direct Vent (Horizontal Option) Series

  • Fury Direct Vent (Vertical Option) Series

Every Rheem gas water heater from Fury series was designed to meet or exceed ANSI standard, energy efficiency requirements, performance, emission and venting codes.

Fury series with the Guardian System

rheem gas water heater furyRheem gas water heater from this series is equipped with the Guardian System, which allows maintenance free operation as the air filtration system prevents the arrestor to become clogged.

Arrestor plate is specially designed feature so it can prevent the ignition of the fuel vapor outside of the heater and its gas burning chamber.

Fury models have another safety system that shuts off the gas and air supply if any spill incident occurs. With such a double protection, any fire or burning of sustained vapor in the combustion chamber is prevented.

Another great feature found on all Fury series that saves on gas cost and provides continual efficiency is the patented system that fights sediment build-up, and it is called EverKleen. Cold water enters the tank through the inlet tube or dip tube and makes the turbulence. Special dip tube design allows water flow to become turbulent.

All the models are certified for use up to 6000 feet (2 km) sea level while some are certified up to 10,200 feet.


Fury Series
TYPE GAL CAP. MODEL NUMBER FIRST HOUR
RATING GPH

ENERGY
FACTOR
NAT.

TALL (HE) 40 42VR40-40F 68 0.62
50 42VR50-40F 83 0.62
TALL 29 22V30F 50 0.62
40 22V4036F1 67 0.59
40 22V40F1 73 0.59
38 42V40F 68 0.60
50 22V50F1 90 0.58
50 42V50-40F 82 0.58
50 42V50-50F 81 0.58
SHORT 30 22V30S-30F 50 0.61
40 42VR40S-40F 72 0.62
40 22V40SF 72 0.59
40 42V40SF 72 0.59
50 42V50SF 84 0.59

Fury models warranty:

  • Fury standard tank warranty - 6 years.

  • Fury water heater replacement parts - 6 years.

  • You can extend 6-year limited tank warranty to 10 years with the ProtectionPlus plan.

Fury Heavy-Duty model

rheem gas water heater fury series

RHEEM Fury Heavy Duty

Rheem gas hot water heaters, Fury Heavy-Duty series, are designed for high volume heating applications; with the tank sizes from 48 to 98 gallons. With the hight of over 62 inches, all the models are considered tall.

The main features for Rheem Fury Heavy-Duty models are high BTU input which is in the range from 50,000 to 75,000 Btu/hr, and fast recovery, making this group more efficient while providing enough hot water for multiple applications.

Other important features are patented magnesium anode rod with the special resistor that protects the tank from corrosion, while providing longer life, specially designed flue baffle for heat saving, Guardian and EverKleen Systems (described above).

All Fury Heavy-Duty models are certified for applications up to 7700 feet or 2.5 km above the sea level, while some up to 10,200 feet.

Heavy Duty series comes with the standard warranty of 8 years while the ProtectionPlus allows an extended warranty of additional 4 years.


emergency plumber

Fury Heavy Duty Series
TYPE GAL CAP. MODEL NUMBER FIRST HOUR
RATING GPH
ENERGY
FACTOR
TALL 48 42V50-65F 98 0.58
60 42V60F 107 0.56
63 42V65F 115 0.55
75 42V75F 141 0.53
98 42V100F 135 0.49

Fury Direct Vent

rheem direct vent water heater

Rheem 22DV50F 50 Gallons

Direct vent Rheem water heaters are designed with the horizontal and vertical venting.

Water heater with the horizontal venting installation can be found in two tank sizes: 40 and 50 gallons. Venting kits are coaxial and adjustable, allowing an easy installation. That means that coaxial vent can swivel 360 degrees.

Direct venting kit has a decent length; it can be installed up to 4 feet above the heater and 4 feet from the outside wall, with the aluminum cap at the end.

Venting kit is designed in such a manner to prevent staining of building exterior (thanks to the aluminum cap) while reducing the heat waste.

To run gases out and use the outside air for gas combustion, Rheem gas water heater from Heavy Duty is using the sealed combustion and low of physics, which doesn't require an electrical power.

Direct vent Rheem water heaters are equipped with a mechanism to prolong the tank life, and protects the tank from the aggressive water and corrosion.

There are also Fury direct vent units with vertical vent option, available in 40 and 50 gallon tank sizes. These Fury models don't need an electrical power to use the outside air for combustion and to vent gases out.

This Fury model features also all the best protection elements as the horizontal system.

Fury Direct Vent Vertical Models
TYPE GAL CAP. MODEL NUMBER FIRST HOUR
RATING GPH
ENERGY
FACTOR
NAT.
TALL 40 22DV40F-VX 66 0.59
50 22DV50F-VX 80 0.59

Fury Direct Vent Horizontal Models
TYPE GAL CAP. MODEL NUMBER FIRST HOUR
RATING GPH
ENERGY
FACTOR
NAT.
TALL 40 22DV40F 66 0.59
50 22DV50F 80 0.58

Ultra Low NOx units

rheem ultra low nox water heater

Rheem 22V50FN

Rheem gas water heater, Fury ultra low NOx models are available in capacity range from 28 gallons to 60 gallons, short and tall in height. All models are high efficiency units and Energy Star compliant, which provides more hot water with less energy consumption.

What makes these gas water heaters different is the environment friendly burner, built from the stainless steel. Such a great quality results in the increase durability and longer life, while producing an ultra low greenhouse gases such as NOx. Another great feature is the Self-Diagnostic System which allows easy troubleshooting if the problem occurs.

Thanks to the power flue damper system, found on the top of water heaters, more heat will be delivered to water.

These Fury green models are also certified for applications up to 10 200 feet or 3400 m above the sea level.



Fury Ultra Low NOx Powered Damper Series
TYPE GAL CAP. MODEL NUMBER FIRST HOUR
RATING GPH
ENERGY
FACTOR
NAT.
TALL 40 23V40NE2 71 0.68
50 23V50NE2 98 0.68

Fury Powered Damper Series
TYPE GAL CAP. MODEL NUMBER FIRST HOUR
RATING GPH
ENERGY
FACTOR
NAT.
TALL 38 43V40E2 68 0.69
50 43V50E2 84 0.67
50 43V50-50E2 87 0.67
SHORT 40 43V40SE2 72 0.67
50 43V50SE2 89 0.67


Where to buy Rheem gas water heaters

You can buy Rheem gas water heater from Fury series at one of the large chain stores, such as Home Depot, through the dealers or conveniently online from Amazon.coM or any other specialized online plumbing store.
